IP input,   3G/HD/SD-SDI, HDMI, CVBS outputs

  • Description
  • Specifications
  • Ordering Info

Description

The QVDEC is part of the high quality professional line of advanced video codecs; a line of compact, powerful and cost-effective products designed for real-time encoding, and decoding for Content Gathering, Monitoring, and Distribution of broadcast quality video over IP networks.

QVDEC’s advanced video transport couples broadcast and networking standards with patented error correction to take advantage of the inherent flexibility of IP and the Internet, providing broadcasters an efficient, affordable and scalable solution for professional quality video distribution quality over nearly any IP network.

The QVDEC provides H.264 High Profile video decompression, up to 1080p50/60, along with support for up to 4 audio channels, multicasting, and unicasting to allow cost-effective audio/video broadcast
and IPTV solutions.

QVDEC - H.264 and MPEG-2 IP Video Decoder

 Applications

• Professional broadcast video distribution
• Live Event / Electronic News Gathering
• Confidence monitoring
• Video conferencing
• IPTV systems

 Key Features

• Real-time HD Video Decoding
   – MPEG-4 AVC / H.264 High, Main and Baseline
      ► Supports CBR & VBR bitrates up to 30 Mbps
      ► Up to level 4.1
   – MPEG-2 Main Profile
   – Up to 4 audio channels (2 stereo pairs)
   – AC3 Pass-Through on S/PDIF
   – Video formats up to 1080p50/60, PAL & NTSC
   – IP streaming input
   – SD and HD Decoding
   – Up and Down Scaling & Frame-rate conversion
 • Robust reception of Video & Audio
   – Patented QVidium® ARQ error correction
   – Industry std. ProMPEG FEC (SMPTE-2022)
   – MPEG Transport Stream
 • Compact, cost-effective solutions
   – Complete receiver 1/2 width - 1RU
 • User-friendly configuration and control
   – WEB-based remote configuration & control
   – SNMP Trap support for NMS systems



Specifications

Please click on “QVDEC Datasheet” for technical specifications.

Ordering Info

QVDEC   –   HD/SD H.264 and MPEG-2 IP decoder, Composite, SDI and HDMI outputs

Available Options:

QVDEC-ARQ-Opt    –   ARQ error correction license

QVRM-KIT    –  1RU rack mount kit
